OnePlus Ace 5 Pro

Brand: OnePlus
Category: Mobile Phones
Add to Compare

Display 6.78-inch (1264x2780)
Processor Snapdragon 8 Elite
Rear Camera 50MP + 8MP + 2MP
RAM 12/16GB
Storage 256GB/512GB/1TB
Battery Capacity 6100mAh
OS Android 15, ColorOS 15

OnePlus Ace 5 Pro Summary

OnePlus Ace 5 Pro smartphone was announced in December 2024. The phone has a 6.78-inch touchscreen display offering a resolution of 2780×1264 pixels (1.5K) at a pixel density of 450 pixels per inch (ppi). An octa-core Snapdragon 8 Elite processor powers the phone. It comes with 12/16GB of RAM. The phone runs Android 15 and is powered by a 6100mAh battery. The phone supports 100W Fast Charging fast charging.

Regarding the cameras, the phone on the rear packs a triple camera setup featuring a 50MP (f/1.8, wide) primary camera; an 8MP (f/2.2, ultra wide-angle) camera, and a 2MP (f/2.4, macro) camera. A single front camera setup for selfies features a 16MP sensor with an f/2.4 aperture.

OnePlus Ace 5 Pro runs ColorOS 15 is based on Android 15 and packs 256GB, 512GB, and 1TB of built-in storage. The phone is a dual-SIM mobile that accepts Nano-SIM and Nano-SIM cards. It was launched in Gray, White, and Purple colors. It has an IP65 rating, ensuring protection against dust and water, and it features a metal body.

Connectivity options include Wi-Fi 7, Wi-Fi 802.11 a/b/g/n, GPS, Bluetooth v5.40, NFC, USB Type-C, 3G, 4G, and 5G with active 4G on both SIM cards. The sensors include an accelerometer, ambient light sensor, compass/ magnetometer, gyroscope, proximity sensor, temperature sensor, and in-display fingerprint sensor.

Specifications

Network

Technology	GSM / CDMA / HSPA / LTE / 5G
2G Bands	GSM 850 / 900 / 1800 / 1900 CDMA 800
3G Bands	HSDPA 800 / 850 / 900 / 1700(AWS) / 2100
4G Bands	1, 3, 4, 5, 8, 18, 19, 26, 28, 34, 38, 39, 40, 41, 42, 48, 66
5G Bands	1, 3, 5, 8, 28, 38, 40, 41, 48, 66, 77, 78, 79, 80, 81, 83, 84, 89 SA/NSA
Speed	HSPA, LTE (CA), 5G

View More View Less

Launch

Announced	2024, December 26
Status	Available. Released 2024, December 31
Price	CN¥3,399 ($465/€450/INR39,670)

Body

Dimensions	161.7 x 75.8 x 8.1 mm (6.37 x 2.98 x 0.32 in)
Weight	203 g or 217 g (7.16 oz)
Build	Glass front (Crystal Shield Glass), glass back (Crystal Shield Glass), aluminum frame
SIM	Nano-SIM + Nano-SIM
Extra	IP65 dust/water resistant

Display

Display Type	LTPO AMOLED, 1B colors, 120Hz, HDR10+, Dolby Vision, 800 nits (typ), 1600 nits (HBM), 4500 nits (peak)
Size	6.78 inches, 111.7 cm2 (~91.2% screen-to-body ratio)
Resolution	1264 x 2780 pixels (~450 ppi density)
Protection	Crystal Shield Glass

Software

OS OS => Every computer system run on a base software called Operating System (OS). Operating System controls all basic operations of the computer (such as smartphone, PDAs, tablet computers and other handheld devices). The Operating System allows the user to install and run third party applications (apps), apps are used to add new functionality to the device.	Android 15, ColorOS 15
Chipset Chipset is a group of integrated circuits designed to perform one or a more dedicated functions, often with real time computing constraints, Popular smartphones are equipped with more advanced embedded chipsets that can do many different tasks depending on their programming.	Qualcomm SM8750-AB Snapdragon 8 Elite (3 nm)
CPU CPU (Central Processing Unit) mostly known as processors, CPU processes instructions in order to carry out certain functions that make your device operate properly. Processors are often described as the brain of computers, smartphones and tablets, Smartphones and tablets rely on processors to carry out their every task, Processors are an incredibly important factor in selecting any type of computing device, including your smartphone.	Octa-core (2x4.32 GHz Oryon V2 Phoenix L + 6x3.53 GHz Oryon V2 Phoenix M)
GPU GPU (Graphics Processing Unit) is a single-chip processor designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display, This includes things such as lighting effects, object transformations, and 3D motion.	Adreno 830

Memory

Expandable	No
Internal Internal Storage is a data storage space (flash memory) mostly used in smartphones, tablets and other electronic devices where operating system, apps, music, photos, videos, files and other user data Is stored.	256GB 12GB RAM, 256GB 16GB RAM, 512GB 12GB RAM, 512GB 16GB RAM, 1TB 16GB RAM
Extra	UFS 4.0

Camera

Rear Dual	50 MP, f/1.8, 24mm (wide), 1/1.56", 1.0µm, PDAF, OIS 8 MP, f/2.2, 16mm, 112˚ (ultrawide), 1/4.0", 1.12µm 2 MP, f/2.4, (macro)
Features	Main: Dual-LED flash, HDR, panorama Front: HDR, panorama
Rear Video	4K@30/60fps, 1080p@30/60/120/240fps, gyro-EIS, OIS
Front camera	16 MP, f/2.4, 24mm (wide), 1/3", 1.0µm
Front Video	1080p@30fps, gyro-EIS

Connectivity

WLAN	Wi-Fi 802.11 a/b/g/n/ac/6/7, dual-band
Bluetooth Bluetooth is a wireless communications technology for exchanging data between mobile phones, headsets, computers and other network devices over short distances without wires, Bluetooth technology was primarily designed to support simple wireless networking of personal consumer devices.	5.4, A2DP, LE, aptX HD, LHDC 5
GPS GPS The Global Positioning System is a satellite-based radio navigation system, GPS permits users to determine their position, velocity and the time 24 hours a day, in all weather, anywhere in the world, In order to locate your position, your device or GPS receiver must have a clear view of the sky.	GPS (L1+L5), GLONASS (G1), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5)
NFC NFC (Near field communication) is a set of standards for smartphones and similar devices to establish peer-to-peer radio communications with each other by touching them together or bringing them into proximity, usually no more than a few inches.	Yes, HCE, eSE, NFC-SIM
Infrared port	Yes
Radio	No
USB	USB Type-C 2.0

Features

Sensors Sensors are electronic components that detects and responds to some type of input from the physical environment. The specific input could be light, heat, motion, moisture, pressure and location, The output is generally a signal that is converted to use in computing systems, a location sensor, such as a GPS receiver is able to detect current location of your electronic device.	Fingerprint (under display, optical), accelerometer, gyro, proximity, compass, color spectrum
Sound	Speaker Phone with stereo speakers
Messaging	SMS(threaded view), MMS, Email, Push Mail, IM
Browser Web Browser => a web browser is a software application used to locate, retrieve and display content on the World Wide Web, including Web pages, images, video and other files, The primary function of a web browser is to render HTML, the code used to design or markup webpages.	HTML5
Games	Built-in + Downloadable
Touch Screen	Yes

Battery

Battery Type Battery Type => Cell phones run on various kinds of batteries depending on the manufacturer, phone size or shape and features. There are basically four types of cell phone batteries => Lithium Polymer, Lithium Ion, Nickel Metal Hydride and Nickel Cadmium.	Si/C (Silicon Carbide)
Capacity Battery Capacity is a measure (typically in Amp-hr) of the charge stored by the battery, and is determined by the mass of active material contained in the battery. The battery capacity represents the maximum amount of energy that can be extracted from the battery under certain conditions.	6100 mAh
Charging Wireless Charging (Inductive Charging) uses an electromagnetic field to transfer energy between two objects. This is usually done with a charging station. Energy is sent through an inductive coupling to an electrical device, which can then use that energy to charge batteries or run the device.	100W wired, 33W PPS, 18W PD/QC, 55% in 15 min, 100% in 35 min (advertised)
